Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm

Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm
Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm

Large Image :  Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm

Product Details:
Place of Origin: China
Brand Name: HUIXUAN
Certification: ASTM,ASME,German DIN,JIS,ISO,BS,API,EN ,DIN
Model Number: Wind Power Flange
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Poly wood case, wood pallet, steel frame support
Delivery Time: 15-50 days
Supply Ability: 2000-4000 Ton/Month
Detailed Product Description
Thickness: 1500mm Overall Size: As Drawing
Treatment: N+T Q+T Material: Steel
Weight: 30T Diameter: 9000mm
High Light:

accurate steel forging

,

industrial forgings



Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm





Products:

Forged flange, wind power flange, tower flange, slewing bearing, Q345 flange, alloy steel flange



Products reference:

Material Q345D,Q345E,50Mn,4140,18CrNiMo7-6



Max. Dia.



9000MM



Apply for



Flange is the part that connected the shafts.



Melting process

LF+EF+VD
Process technology



Forging+heat treatment+rough machining+finish machining



Forging ratio



≥5



Applicable standard



ASTM,ASME,German DIN,JIS,ISO,BS,API,EN ,DIN



Executive standard

JB/GB/EN/DIN/JIS/ASME/ASTM/ISO



Certification authority



ISO9001:2008, TÜV, BV, LR, ABS, RINA, GL, KR, DNV, NK, PED.



Delivery terms



Rough machining(N+T); finish machining(Q+T)



Test equipment



Spectrograph, UT device, tensile and compact test machine, metalloscope,external micrometer, bore dial indicator, hardness testing device and so on.



Service



Our service included the forging, process, heat treatment, finish machining, package, local logistics, customers clearance and maritime transport. We took the customer’s requirements as the principal thing, and pay attention on the products quality.



Custom properties





Material elements

C Si Mn P S Cr Ni Mo Cu
4140 0.38-0.43 0.15-0.35 0.60-0.90 ≤0.035 ≤0.040 0.80-1.10 -- 0.15-0.25 -
Q345E 0.13-0.20 0.17-0.37 1.20-1.60 ≤0.030 ≤0.030 ≤0.30 ≤0.30 --
18CrNiMo7-6 0.15-0.21 0.17-0.35 0.50-0.90 ≤0.025 ≤0.025 1.50-1.80 1.40-1.70 0.25-0.35
50Mn 0.48-0.56 0.17-0.37 0.70-1.00 0.035 0.035 0.25 0.30 -- 0.48-0.56





Mechainal properties



Dia.(mm)



TS/Rm(Mpa)



YS/Rp0.2(Mpa)



EL/A5(%)



RA/Z(%)



Type Of notch



Impact energy



HBW

4140 Ø10 740~1000 450~850 ≥12 ≥25 V ≥40 ≤250HBS
Q345E Ø10 470-630 ≥345 ≥21 -- V -20℃≥34 ==
18CrNiMo7-6 Ø15 ≥980 ≥785 ≥9 ≥40 V ≥47 ≤269HBS
50Mn Ø25 ≥645 ≥390 ≥13 ≥40 V ≥31 ≤255HBS


Process procedure:

Forging process flow quality control: Raw material steel ingot into warehouse(test the chemical content)Heating(Furnace temperture test) Heat treatment after forging(Furnace temperture test) Discharge the furnace(blank inspection)Machining Inspection(UT,MT,Visal diamention, hardness) QT Inspection(UT, mechanical properties, hardness, grain size) Finish machining Inspection (dimension) Packing and Marking(steel stamp, mark)Storage Shipment



5th, Commerce clause



Max. weight

30T

MOQ



1PC



Delivery time



15-50 days



Package



Poly wood case, wood pallet, steel frame support



Delivery terms

FOB;CIF;CFR;DDU;



Payment terms

T/T,LC



Type of shipping



By ocean, air



Keywords



Various of shafts made of alloy steel, carbon steel, stainless steel that mainly used for wind power equipment, slewing bearing equipment, engineering machinery, pressure vessel, gear transmission and so on that have good mechanical properties and weldability. Flange is the part that connected the shafts. We can produce the flange with material of WCB(carbon steel),LCB(long chain branching),LC3(3.5% nickel steel),WC5(1.25%Cr 0.5% Mo Steel),WC9(2.25%Cr),C5(5%Cr 0.5%Mo),C12(9%Cr1%Mo),CA6NM(4(12% Cr steel),CA15(4)(12%Cr),CF8M(316 stainless steel),CF8C(347 stainless steel),CF8(304 stainless steel),CF3(304L stainless steel),CF3M(316L stainless steel),CN7M(alloy steel),M35-1(monel),N7M(hastelloy B),CW6M(hass nickel steel C),CY40(inconel nickel steel)and so on.



 Advantage



Heavy Steel Wind Power Flange Forging Q345D 50Mn 4140 Dia 9000mm 0
