ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality

ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality
ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality

Large Image :  ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality

Product Details:
Place of Origin: China
Brand Name: HUIXUAN
Certification: ISO9001：2008，BV,SGS,IST,UL.CTI
Model Number: 20M
Payment & Shipping Terms:
Minimum Order Quantity: 10PC
Price: Negotiable
Packaging Details: wood pallet,steel frame
Delivery Time: 30-50 days
Payment Terms: L/C, T/T
Supply Ability: 2000-4000 Ton/Month
Contact Now
Detailed Product Description
Max Length: 20M Foring Ratio: ≥5
Max Weight: 3000kg Melting Process: LF+EF+VD(ESR)
MOQ: 10PC Payment Term: T/T,LC



     ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality



Products reference:

 Material H13, T20502, 4Cr5MoSiV1, 1.2740
Forging equipment



2000T forging round machine



Application



Important perforating tool in seamless steel pipe rolling processing
Melting process LF+EF+VD(ESR)
Process technology



Forging+heat treatment+rough machining+finish machining



Forging ratio



≥5
Applicable standard



ASTM,ASME,DIN,JIS,ISO,BS,API,EN
Executive standard



JB/GB/EN/DIN/JIS/ASME/ASTM/ISO
Certification authority



ISO,BV,SGS, IST, UL,CTI
Delivery term



Rough machining(N+T); finish machining(Q+T)
Test equipment



Spectrograph,UT device,tensile and impact test machine,metalloscope,hardness test machine
Service Our service included the forging, process, heat treatment, finish machining, package, local logistics, customers clearance and maritime transport. We took the customer’s requirements as the principal thing, and pay attention on the products quality.



Custom properties:

Chemical composition C Si Mn P S Cr V Mo



Others
T20502 0.32-0.45 0.80-1.20 0.20-0.50 ≤0.030 ≤0.030 4.75-5.50 0.80-1.2- 1.10-1.75
1.2740 0.24-0.32 0.30-0.50 0.20-0.40 ≤0.030 ≤0.030 0.60-0.90 0.25-0.32 0.50-0.70



Process procedure:

Forging process flow quality control: Raw material steel ingot into warehouse(test the chemical content) → Cutting→ Heating(Furnace temperture test) → Heat treatment after forging(Furnace temperture test) Discharge the furnace(blank inspection)→ Machining→ Inspection(UT,MT,Visal diamention, hardness)→ QT→ Inspection(UT, mechanical properties, hardness, grain size)→ Finish machining→ Inspection (dimension)→ Packing and Marking(steel stamp, mark)→ Storage Shipment



Commerce clause:

Max weight 3000KG
MOQ 10PC
Delivery time 20-50 days
Package Wooden,pallet,steel frame
Delivery term FOB;CIF;CFR；DDU；
Payment term T/T,LC
Transportaion

Ocean,air



Keywords:

According to different material,Mandrel bar is used for various seamless pipe perforating,

Die block steel mandrel bar is used for stainless steel pipe,normal high alloy steel mandrel bar is used for alloy steel pipe.



Advantage:

1.High-precision dimensional tolerance;

2.Excellent mechanical properties;

3.Produce different dimension based on customer’s requirements;

4.Advanced manufacture equipments and inspection devices;

5.Excellent technical personality;

6.Control the production procedure strictly;

7.Pay attention on the package protection;

8.Quality full service.

ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality 0ASTM DIN Standard High-Pressure Boiler Piping Fitting,Forged Tube High Quality 1
